Benchmarking on pseudo-ST data

1. Import CellRefiner and packages

[2]:

import scanpy as sc
import squidpy as sq
from anndata import AnnData
import pandas as pd
import numpy as np
from matplotlib import pyplot as plt
import cellrefiner as cr

2. Load Data

The MERFISH dataset is available via the squidpy package.

[3]:

ad = sq.datasets.merfish()
ad = ad[ad.obs.Bregma == -9]

Generate sc data

[4]:

ad_sc=AnnData(ad.X)
ad_sc.obs_names=[f'Cell_{i}' for i in range(ad_sc.shape[0])]
ad_sc.var_names=ad.var_names
ad_sc.obsm['spatial']=ad.obsm['spatial']
ad_sc.obs['Cell_type']=pd.Categorical(ad.obs['Cell_class'])

Generate pseudo st data

[5]:

from scipy.spatial import KDTree
A=ad.obsm['spatial']
n1=32
n2=32
R=80/5000
max_neighbors=5
min_coords = np.min(A, axis=0)
max_coords = np.max(A, axis=0)

# Create evenly spaced grid
x = np.linspace(min_coords[0], max_coords[0], n1)
y = np.linspace(min_coords[1], max_coords[1], n2)

# Create meshgrid
X, Y = np.meshgrid(x, y)

# Reshape into a list of points
grid_points = np.vstack([X.ravel(), Y.ravel()]).T

# Build KD-Tree for efficient nearest neighbor search
tree = KDTree(A)

# Find neighbors within distance R for each grid point
neighbors_list = []
distances_list = []

for point in grid_points:
    # Query the KD-Tree for neighbors within distance R
    distances, indices = tree.query(point, k=len(A), distance_upper_bound=R)

    # Filter out invalid indices (indicated by index == len(A))
    valid_mask = indices < len(A)
    valid_indices = indices[valid_mask]
    valid_distances = distances[valid_mask]

    # Take at most max_neighbors
    if len(valid_indices) > max_neighbors:
        # Sort by distance and take the closest max_neighbors
        sorted_idx = np.argsort(valid_distances)[:max_neighbors]
        valid_indices = valid_indices[sorted_idx]

    neighbors_list.append(valid_indices)
if type(ad.X)=='scipy.sparse._csr.csr_matrix':
    M=ad.X.toarray()
else:
    M=ad.X

# Initialize the new matrix with zeros
M1 = np.zeros((len(neighbors_list), M.shape[1]))

# For each grid point
for i, neighbor_indices in enumerate(neighbors_list):
    if len(neighbor_indices) > 0:  # Check if there are any neighbors
        # Sum the rows of M indexed by the neighbors
        M1[i] = np.sum(M[neighbor_indices], axis=0)

[6]:

ad_st=AnnData(M1)
ad_st.obsm['spatial']=grid_points
ad_st.obs_names=[f'Spot_{i}' for i in range(ad_st.shape[0])]
ad_st.var_names=ad.var_names

Preprocess

[7]:

sc.pp.filter_cells(ad_sc,min_genes=3)
sc.pp.filter_genes(ad_sc,min_cells=3)
sc.pp.normalize_total(ad_sc)
sc.pp.log1p(ad_sc)
sc.pp.highly_variable_genes(ad_sc)
ad_sc = ad_sc[:,ad_sc.var['highly_variable']]
